Human body impactor 45 kg

Used for:

Stability testing, for example shower enclosures shall withstand an energy representing the impact of a human body on a large impact area (e.g. blow from shoulder, fall) without any functional deterioration which could result in injury to the user.

Conforms to:

EN 14428, ISO 29584, ANSI Z97.1, EN 81-50

Principle of operation:

the impactor is released so that it swings in a pendulum arc and strikes the test piece. Examine the fractures to the specimen.

Features:

For Ansi z97.1 and ISO 29584, To reduce bag damage during testing, the exterior of the leather bag surface is covered with glass filament reinforced pressure sensitive polyester adhesive tape.

Technical characteristics:

Leather bag

The bag is filled with lead shots of 2.4mm or 3.5mm in diameter, depending on the norm.
